Network Pendant Speaker PoE 10W

• 1 × 1.0-inch tweeter and 1 × 6.5-inch woofer
• Rated Power: 10 W
• Sensitivity(1 m, 1 W): 89 dB
• Max. SPL: 98 dB
• Frequency Response: 120 Hz to 20 kHz
• Support Hi PoE
• Support schedule/live/emergency broadcast, alarm linkage, two-way audio, TTS
• White or black appearance optional

• Network Protocol IPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP

• Type MEMS
• Amount 2
• Frequency Response 100 Hz to 10 kHz
• Sensitivity -38dBV/Pa

• Impedance 8Ω
• Rated Power 10W
• Total Harmonic Distortion (THD) ≤1%
• Sensitivity(1 m, 1 W) 89dB
• Max. Acoustic Pressure 98dB
• Frequency Response 120Hz~20kHz(-10dB)
• Speaker Unit 1 × 1.0-inch tweeter and 1 × 6.5-inch woofer
• Coverage Angle Conical Coverage: 88°

• Audio Algorithm AEC、AGC、ANS、DRC
• Audio Bit Rate

  G.711ulaw（64 Kbps）/G.711alaw（64 Kbps）/MP3（128 Kbps）

  Sampling bit width: 16 bits

• Speech Synthesis Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French

• Alarm Alarm in
• Network Interface RJ45 10 M/100 M Adaptive Ethernet port × 1
• Local Storage Built-in 64 GB EMMC (Audio file storage is 55 GB.)
• Audio In 3.5 mm audio interface × 1
• LED Indicator

  Solid green: normal working

  Flashing green: intercom in progress

  Solid red: start or network disconnection

  Flashing red: upgrading

• Reset Support

• Power 24 VDC ± 10%, 2.5 A, max. 60 W, PoE: 50 V to 57 V, 0 A to 1.6 A, max. 71 W
• Material

  Main body: PC

  Base: ABS

• Dimension Ø242.78 mm × 214.78 mm (9.56" × 8.46")
• Approx. 2.7 kg (5.95 lb.)
• Language 41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese
• Package Dimension 305 mm × 305 mm × 315 mm (12.01" × 12.01" × 12.4")
• With Package Weight Approx. 2.9 kg (6.49 lb.)
• Packing List

  Device × 1

  Regulatory Compliance and Safety Information × 1

  2-pin phoenix connector × 1

  4-pin phoenix connector ×1

• Bluetooth Bluetooth 5.0, 10 m
• Operating Temperature -10 °C to 45 °C
• Operating Humidity ＜90% (No condensation)
