2.25-inch Network Linear Speaker Column 200W

• Digitaal regelbare lineaire audiozuil met 16 neodymiummagneten van 2,25 inch, voorzien van een ingebouwde DSP en versterker.
• Digitaal regelbare verticale bundelrichting met een horizontale dekking van 160°, flexibel aan te passen aan verschillende ruimte-indelingen.
• Ondersteunt diverse bundelbesturingsalgoritmes, waaronder bundelhoek, bundelbreedte, multi-beam ontwerp en geluids- en kleurbalans, en aangepaste aanpassing van het geluidsveld voor een optimale luisterervaring in diverse ruimtes.
• Ingebouwde audio-algoritmes, waaronder mixen, equalizer en ruisonderdrukking, voor uitstekende audioprestaties.
• Ondersteunt het internationale AES67-transmissieprotocol (latere versies ondersteunen AES67-compatibiliteit met externe partijen), wat zorgt voor een lage latentie en hoge synchronisatie bij netwerkaudiosystemen.
• Ondersteunt apparaatactivering, netwerkinstellingen, routeringsinstellingen, parameterinstellingen en andere gerelateerde bewerkingen via de audio-assistent.

• Impedance 6 Ω
• Channel Amount Mono
• Rated Power 200 W
• Total Harmonic Distortion (THD) <3% @1 kHz
• Sensitivity(1 m, 1 W) 89 dB@1 m, 1 W
• Audio In LINE IN × 1，Green Phoenix Terminal
• F0 110 Hz
• Noise Floor(A-weighted): <200 μV
• Maximum Sound Pressure Level 116 dB (1 m)
• Frequency Response

  (-3 dB): 125 Hz to 16 kHz

  (-10 dB): 100 Hz to 18 kHz

• Sampling Rate 48 kHz
• Quantization Bits 24 bit
• Speaker Unit 2.25-inch Neodymium Full-Range Speaker
• Coverage Angle 160°(H) × ±30°(V)
• Beamwidth Adjustable between 10° and 50°, with a tuning step of 4°
• Directivity Angle Adjustable within ±30°, with a tuning step of 5°

• Audio Algorithm COMP, Delay, Mixing, ALC, PEQ, Noise Gate, Beam Control
• Protection Function Power reverse protection, overcurrent protection, overvoltage protection, overload protection, PA thermal protection, PA short-circuit protection, PA output overvoltage protection

• Network Protocol AES67, TCP/IP, ICMP, HTTP, HTTPS, DNS, RTP, RTSP, RTCP, NTP, QoS, UDP, SSL/TLS, IEEE1588
• Interface Protocol (API)OTAP
• Network Security Password protection, complicated password, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, security audit log, TLS 1.2/1.3

• Network Interface RJ45 1000 M Ethernet port × 1
• Local Storage Built-in 4 GB EMMC × 1, 1 GB DDR4 × 1
• Audio In LINE IN × 1, Green Phoenix connector
• Audio Out Network output
• LED Indicator

  Device Indicator: red and white

  Light Off: The device is not powered on. The program is not started.

  Breathing White: The device is powering on and initializing

  Solid White: The device is running normally

  Flashing White: Device recognition is in progress (when there are multiple devices in the system, click Identify Device on the client

  Flashing Red: Device fault.

  Analog Audio Indicator: red, yellow, and green

  Light off: Less than -60 dBFS

  Green: -59 dBFS to -24 dBFS

  Yellow: -23 dBFS to -1 dBFS

  Red: No less than 0 dBFS

• Reset Support

• System Requirement

  Recommended system configuration for Audio Assistant Tool:

  Operating System: Windows(R) 10 (recommended), Compatible with Windows(R) 7 / Windows(R) 8.1 / Windows(R) 11

  CPU: Intel(R) i3-9100@4.2 GHz or above

  RAM: 4 GB and above

  Video Card: GT1030 D5

  HDD: 20 GB

  Display: 1920 × 1080 and above

• Power AC 220 V, 2.1 A, 50 Hz
• Material Enclosure: Metal; Top cover: Metal; Bracket 1: Metal; Bracket 2: Plastic
• Dimension 990.6 mm × 111.5 mm × 138 mm (39" × 4.39" × 5.43")
• Approx. 8.8 kg (19.4 lb.)
• Operating Condition -10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
• Package Dimension 1145 mm × 252 mm × 308 mm (45.08" × 9.92" × 12.13")
• With Package Weight Approx. 11.2 kg (24.7 lb.)
• Color Grey
• Installation Wall mounting, Wall thickness ≥75 mm (2.95")
• System Language English
• Mounting Bracket Included: Wall mount bracket; Adjustable-angle wall mount bracket
